Myydään: RME ADI-642 - Blue | | Lisätty: 01.09.2024 Voimassa: 04.09.2024
| | ![](/img/x.gif) | Erittäin hyvässä kunnossa kiinni räkissä ollut samassa tilassa.
The RME ADI-642, an 8-channel format converter from MADI to AES and vice versa, is the latest addition to RME's successful MADI series. Amongst other applications, the unit can serve as ideal AES/EBU frontend for the Hammerfall DSP MADI PCI card. Up to 192 kHz at 24 bit are supported. Its most outstanding feature is an easy-to-use 72x72 routing matrix, which can assign an individual input channel to every single output channel, allowing free configuration of all 64 MADI channels and the 8 AES channels. Additional features include:
Native support for AES Double and Quad Wire
Native support for MADI Double and Quad Wire
Direct conversion between these formats
Automatic Delay Compensation when using more than one unit
Analog stereo monitor output, up to 192 kHz
Detailed status display for MADI and AES
Completely remote controlable via MIDI
Transfer of MIDI data via MADI
SteadyClock for maximum jitter reduction and clock regeneration
The compact unit with 19" width and 1 unit height serves as format converter MADI to/from AES . MADI handles 64 channels of 24 bit audio at sampling frequencies up to 48kHz, 32 channels up to 96kHz, and 16 channels up to 192kHz. All channels are transferred across a single cable, either coaxial (BNC) or optical network cable. In both cases, cable lengths of more than 100 meters can be achieved. The AES/EBU channels are provided via 4 XLR inputs and outputs, respectively. The ADI-642 accepts 56 channels and 64 channels as well as 96k and 192k frame at its input, and can be set to generate those formats at its output. This way the ADI-642 even serves as perfect interface between otherwise incompatible MADI devices.
Listed 18 hours ago
Condition Mint (Used)
Mint items are in essentially new original condition but have been opened or played.Learn more
Brand
RME
Model
ADI-642 MADI / AES Digital Format Converter
Finish
Blue
Categories
Utility
Year
2014
Made In
Germany
Sample Rate
192 khz
Digital Output Format
MADI
AES/EBU
Digital Input Format
AES/EBU
MADI
Electronics Digital Bit Depth
24-bit Format
19-inch Rackmount
Number of Channels 8
Incluted short aes/ebu cablesHinta: 1300 €
| ![Ilmoituksen #1937899 kuva](/dyn/tori/1711968-q.jpg) Yhteensä 2 kuvaa•• | ![](/img/x.gif) | Osasto: Studio/PC › Muut Paikkakunta: Helsinki (Etelä-Suomen lääni)
| |
Myydään: RME ADI-648 - Grey | | Lisätty: 01.09.2024 Voimassa: 04.09.2024
| | ![](/img/x.gif) | Hyvä kuntoinen ja siisti pidetty räkissä
The RME ADI-648 MADI to ADAT Converter consists of two 64-channel digital format converters in reference quality, in a standard 19 inch box with 1 unit height. The compact device has numerous extraordinary features like Intelligent Clock Control, SyncCheck, SyncAlign, Bitclock PLL, SteadyClock, patchbay functionality, and a 16x16 Matrix router.
The RME ADI-648 MADI to ADAT Converter offers format conversion from MADI to ADAT and vice-versa. The RME ADI-648 thus combines the world's most successful multi-Channel interface with the professionals' exclusive high-end interface. MADI offers 64 channels of 24-Bit audio at up to 48 kHz sample rate, and 32 channels at up to 96 kHz. Transmission happens over a single line, either coaxial (BNC) or fiber optic (network). In both cases the cable length can be more than 100 meters.
The MADI channels are transferred from and to 8 ADAT optical inputs and 8 outputs via TOSLINK. Furthermore, the RME ADI-648 contains an easy-configurable 8-Channel 16x16 Matrix Router. Any of the outputs, which are divided into 8-Channel blocks, can be fed from any 8-Channel input block, both on the ADAT and the MADI side. With this, there is not only free routing within the M-A and the A-M conversion, but also splitting and routing within the same format. An 8-Channel input block can be routed to any number of output blocks in parallel. Using more than one unit, several MADI signals can be combined to one (merging).
The RME ADI-648 is compatible to all forms of increasing the sample rate (Double Speed). It supplies word clock in single or double speed, distributes 96 kHz signals in Double Wire mode into the MADI data stream, or per Sample Split (S/MUX) to the ADAT ports, but is also capable of double MADI rate (96k Frame). The RME ADI-648 thus also represents an ideal MADI front-end for the Hammerfall and Hammerfall DSP series.
RME ADI-648 MADI to ADAT Converter Connectivity
1 x MADI I/O (Optical and Coaxial)
8 x ADAT I/O (Optical)
1 x MIDI I/O
Word Clock I/O
RME Remote
RME ADI-648 MADI to ADAT Converter Features
SyncAlign ® and SyncCheck ®, technologies known from and proven by other RME products, allow for perfect sync between all channels and easy notification of error states
Multiple devices can be cascaded and synchronized sample-accurate using word clock
The RME ADI-648 accepts 56 channels, 64 channels and 96k frame at its input, and can be set to generate those formats at its output
RME ADI-648 MADI to ADAT Converter Specifications
Input MADI: 1 x BNC, 1 x optical
Output MADI: 1 x BNC, 1 x optical
Input ADAT Optical: 8 x TOSLINK, 24-Bit, Bitclock PLL
Output ADAT Optical: 8 x TOSLINK, 24-Bit
Input Word Clock: BNC, Signal Adaptation Circuit (functional from 1.2 Vpp input signal), switchable termination
Output Word Clock: BNC, low-impedance driver stage, 4 Vpp into 75 Ohms, short-circuit-proof
MIDI Input & Output: via two 5-pin DIN jacks
Sync Sources: MADI, ADAT optical, word clock, internal
Varipitch: By input signal or word clock
Sample Rates: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, variable (Sync/word clock)
Sample Rate Range: MADI: 32 kHz - 96 kHz, word clock: 27 kHz-105 kHz, ADAT: 33 kHz - 57 kHz
Jitter: Internal clock < 1 ns, word clock In < 2 ns, ADAT In < 2 ns
Jitter Suppression On External Clock: circa 30 dB (2.4 kHz)
Jitter Sensitivity: All PLLs operate even at 100 ns Jitter without problems
Power Supply: internal switching mode ps, 100 V-240 V AC, 50-60 Hz, 10 Watts
Dimensions: 483 x 44 x 200 mm
User Manual
incluted 8 optical cables
.....paljon lisää tietoa netistä tänne ei mahdu kaikkiHinta: 1100 €
| ![Ilmoituksen #1940723 kuva](/dyn/tori/1719145-q.jpg) Yhteensä 2 kuvaa•• | ![](/img/x.gif) | Osasto: Studio/PC › Muut Paikkakunta: Helsinki (Etelä-Suomen lääni)
| |
Ostetaan: Tascam 414 mkII Portastudio | | Lisätty: 31.08.2024 Voimassa: 06.09.2024
| | ![](/img/x.gif) | Tascamin portastudio 414 mkII tai 424 mkIII etsinnässä, kaikkia eri malleja voi toki tarjota. Ilmottele jos oot aatellu luopua niin katotaan sopiva hinta, kiitos paljon! Onnistuu myös noutaa matkalla pohjosesta etelään. | ![](/dyn/tori/1726324-n.jpg)
| ![](/img/x.gif) | Osasto: Studio/PC › Mikserit, raiturit Paikkakunta: Utsjoki (Lapin lääni) Puhelin: Näkyy kirjautuneille Sähköposti: Näkyy kirjautuneille
| |
Ostetaan: O: Rme Micstasy | | Lisätty: 31.08.2024 Voimassa: 05.09.2024
| | ![](/img/x.gif) | Hakusessa kyseinen laitos. Jos sulta sellainen myytäväksi löytyy niin pistä sähköpostia tai pirauta niin ihmetellään lisää. | ![](/img/x.gif)
| ![](/img/x.gif) | Osasto: Studio/PC › Vahvistimet Paikkakunta: Vantaa (Etelä-Suomen lääni) Puhelin: Näkyy kirjautuneille Sähköposti: Näkyy kirjautuneille
| |
