| Myydään: RME ADI-642 - Blue | | Lisätty: 09.06.2024
Voimassa: 14.06.2024
| |  | Erittäin hyvässä kunnossa kiinni räkissä ollut samassa tilassa.
The RME ADI-642, an 8-channel format converter from MADI to AES and vice versa, is the latest addition to RME's successful MADI series. Amongst other applications, the unit can serve as ideal AES/EBU frontend for the Hammerfall DSP MADI PCI card. Up to 192 kHz at 24 bit are supported. Its most outstanding feature is an easy-to-use 72x72 routing matrix, which can assign an individual input channel to every single output channel, allowing free configuration of all 64 MADI channels and the 8 AES channels. Additional features include:
Native support for AES Double and Quad Wire
Native support for MADI Double and Quad Wire
Direct conversion between these formats
Automatic Delay Compensation when using more than one unit
Analog stereo monitor output, up to 192 kHz
Detailed status display for MADI and AES
Completely remote controlable via MIDI
Transfer of MIDI data via MADI
SteadyClock for maximum jitter reduction and clock regeneration
The compact unit with 19" width and 1 unit height serves as format converter MADI to/from AES . MADI handles 64 channels of 24 bit audio at sampling frequencies up to 48kHz, 32 channels up to 96kHz, and 16 channels up to 192kHz. All channels are transferred across a single cable, either coaxial (BNC) or optical network cable. In both cases, cable lengths of more than 100 meters can be achieved. The AES/EBU channels are provided via 4 XLR inputs and outputs, respectively. The ADI-642 accepts 56 channels and 64 channels as well as 96k and 192k frame at its input, and can be set to generate those formats at its output. This way the ADI-642 even serves as perfect interface between otherwise incompatible MADI devices.
Listed 18 hours ago
Condition Mint (Used)
Mint items are in essentially new original condition but have been opened or played.Learn more
Brand
RME
Model
ADI-642 MADI / AES Digital Format Converter
Finish
Blue
Categories
Utility
Year
2014
Made In
Germany
Sample Rate
192 khz
Digital Output Format
MADI
AES/EBU
Digital Input Format
AES/EBU
MADI
Electronics Digital Bit Depth
24-bit Format
19-inch Rackmount
Number of Channels 8
Incluted short aes/ebu cablesHinta: 1500 €
|
Yhteensä 2 kuvaa•• | | Osasto: Studio/PC › Äänikortit
Paikkakunta: Helsinki (Etelä-Suomen lääni)
| |
